Product Details
Model Number
NST-6250
Compliance
CE Certified
Warranty
1 Year
Temperature Control/Stability
0.1 Degree C/±0.5 Degree C
Vacuum Degree
133Pa
Ambient Temperature
+5~40 Degree C
Payment Terms
L/C, T/T, Western Union
NST 252L 250°C Vacuum Oven (28x24x24″ ) with Digital Temperature Controller & Inner Chamber – DZF-6250
NST-DZF-6250 is a middle size vacuum oven with max working temperature 250°C and 252 Liter capacity. The oven adopts heat radiant wall system providing optimal uniformity and conserves chamber space for drying, curing, vacuum embedding, and plating applications.
Temperature Controller
Single point temperature setting
- Built-in over-temperature protection
- PID precise temperature control
- Temperature control accuracy: +/-0.1°C
- Temperature uniformity: +/-2.5°C @ 100°C, 25″ Hg at center 6″x6″ area only
Attention
- It’s normal that the SS chamber wall will slightly deform and loose its shine during high-temperature operation. However, this would not affect any functionality.
- Please do not place the sample on the chamber bottom directly.
Technical Specifications
| Model | 6052 | 6210 | 6090 | 6250 | 6050 | 6051 | 6021 | 6020 | 6030A Special for chemistriy |
6030B/6050B Special for chemistriy |
|||
| Electrical Requirements | 220V 50Hz | 380V 50Hz |
220V 50Hz | ||||||||||
| Input Power | 2100W | 1400W | 3000W | 1400W | 1400W | 500W | 500W | 500W | 400W/700W | ||||
| Temperature Range | RT | RT+10~250℃ | RT+10~200℃ | RT+10~250℃ | RT+10~65℃ | ||||||||
| Temperature Control/Stability |
0.1℃/±0.5℃ | ||||||||||||
| Vacuum Degree | 133Pa | ||||||||||||
| Ambient Temperature | +5~40℃ | ||||||||||||
| Interior Dimension (mm)W*D*H |
415*370*345 | 560*640*600 | 450*450*450 | 700*600*600 | 415*370*345 | 300*300*275 | 320*320*300 | 320*320*300 415*370*345 |
|||||
| Overall Dimension | 720*525*535 | 720*820*1750 | 615*590*1470 | 1050*760*910 | 720*525*535 | 580*450*450 | 630*510*460 | 610*510*490 710*560*550 |
|||||
| Shelves | 2(pcs) | 3(pcs) | 2(pcs) | 3(pcs) | 2(pcs) |
1(pcs) |
1(pcs) |
1/2 (pcs) | |||||
| Chamber Material | Stainless | Rolled sheet | Stainless | ||||||||||
| Vacuum Pump (Optional) |
Ultimate Vacuum Level: 1000 millitorrs. | ||||||||||||
| Fittings | This oven comes with a KF-25 vacuum connector which allows you set up a quick connection to the vacuum pump. | ||||||||||||
| Compliance | CE Certified | ||||||||||||
| Warranty | One years limited warranty with lifetime technical support | ||||||||||||
